New design - higher installation depth

Introducing the Rain Bloc Compact 300, a revolutionary tool for managing stormwater. Higher installation depths are possible thanks to its innovative design, and versatile connection choices in a range of diameters (DN 100, 120, 150, and 200) guarantee a custom fit for your project. This system can tackle even the most challenging drainage tasks thanks to its outstanding maximum installation depth of 7.5 metres. Additionally, it offers a handy DN 100 (4") top connection and simplifies configuration with pre-installed pins for vertical connection. The Rain Bloc Compact 300 raises the bar for efficiency and adaptability in stormwater management.



 Vehicle weight <3 tonnesVehicle weight <9 tonnesVehicle weight <12 tonnesVehicle weight <30 tonnesVehicle weight <40 tonnes
Minimum cover depth (m)0.500.550.650.701.10
Maximum cover depth (m)3.003.003.002.752.50



Sizing

Length [mm]Width [mm]Height [mm]order no.add to enquiry
1200600420360050

calculated size Request for information

Accessory
